Dimplex BLF50 - Manual (Page 19)

19
Operation
Remote Control
The fireplace is supplied with a
radio frequency remote control.
This remote control has a range
of approximately 50 feet (15.25
m), it does not have to be pointed
at the fireplace and can pass
through most obstacles (including
walls). It is supplied with one
of hundreds of independent
frequencies to prevent
interference with other units.
!
NOTE: Before attempting
any operation with the remote,
pull the plastic insulator strip
out from between the remote
casing and battery cover
(Figure 19).
Remote Control Initialization/
Reprogramming
If the remote control or remote
control receiver has been
replaced, follow these steps to
initialize the remote control and
receiver:
Ensure that power is supplied 1.
through the main service
panel.
Turn on/off switch to on
2.
(Figure 18A).
move the 3-Position switch
3.
to the “ REMOTE ” position
(Figure 18b).
Press and hold the Manual 4.
Control button marked “ I ” for
five (5) seconds. After five (5)
seconds, there is a 10 second
window to press any button
on the remote control .
Press any button on the 5.
remote control within that 10
seconds.
This will synchronize the remote
control and receiver.
Remote Control Usage
The remote control operates the
fireplace levels sequentially (from
off): flames only; to flames and
low heat; to flames and high heat.
The level is increased every time
the ON button is pressed on the
remote control and the fireplace
can be turned off at any point by
pressing the oFF button.
Figure 19
Off
Button
On
Button
Battery
cover
Plastic
strip
