background image

12

www.dimplex.com

Fireplace Installation

refer to Front Glass

16.

Installation section, page

16 for final installation

procedures.

Surface Installation

CAUTION: Two people may

be required for various steps

of this procedure.

Choose a location which has

1.

a minimum of two (2) wall

studs available for mounting.
Choose your method of

2.

supplying power to the unit:

Plug in to an existing outlet

or install an outlet nearby.
hard wire the fireplace. Follow

the hard wiring instructions on

page 9.

WARNINg: Do not attempt

to wire your own new outlets or

circuits. To reduce the risk of fire,

electric shock or injury to persons,

always use a licensed electrician.
Ensure that the on/off switch

is set to the Off position (refer to

operation section) and that the

circuit on which the fireplace is to

be installed has the power cut off at

the service panel until installation is

complete.

Remove the partially

3.

reflective glass from the

fireplace:

Lay fireplace on its back.

Remove two (2) Phillips

screws from each of the two

(2) glass brackets (Figure 2,

page 9).
remove glass brackets.

With one hand keeping

pressure on the partially

reflective glass, tilt the

fireplace upright and slightly

forward to allow the partially

reflective glass to fall out of

the inside framing.

CAUTION: Partially reflective

glass is not tempered. Do

not bump or drop the partially

reflective glass to avoid breakage

and personal injury.

remove partially reflective

glass from fireplace.

Position the fireplace on a wall

4.

at the position where it will be

mounted (Figure 9). use a

bubble level (one is supplied)

to ensure that fireplace is level

on the wall.
Ensuring that at least two (2)

5.

key-holes line up with a wall

stud (key-holes are spaced

at four (4) inch (10.2 cm)

centers), mark the location

of four (4) screw locations on
