Dimplex SP420 - Manual

THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE.
Dimensions
(millimetres)
Installation and Operating Instructions
Electrical
08/18887/1 Issue 1
Fig. 1
Important Safety Advice:
When using electrical appliances, basic
precautions should be followed to reduce the risk
of fire, electric shock, and injury to persons,
including the following :
• If the appliance is damaged, check
immediately with the supplier before
installation and operation.
• This heater must not be used if the front glass
is damaged.
• Do not use this heater in the immediate
surroundings of a bath, shower or swimming
pool .
• Do not use outdoors.
• This heater must not be located immediately
above or below a fixed socket outlet or
connection box.
• Do not cover - Overheating will result if the
heater is accidentally covered.
• In the event of a fault unplug the heater.
• Unplug the heater when not required for long
periods.
• Although this heater complies with safety
standards, we do not recommend its use on
deep pile carpets or on long hair type of rugs.
• Do not leave young children, the elderly, or
the infirm unsupervised in the vicinity of the
heater.
• The appliance must be positioned so that the
plug is accessible.
• If the supply cord is damaged it must be
replaced by the manufacturer or service agent
or similarly qualified person in order to avoid
a hazard.
WARNING – THIS APPLIANCE MUST BE EARTHED
This heater must be used on an AC ~ supply only and the
voltage marked on the heater must correspond to the supply
voltage.
Do not switch the appliance on until properly installed. Please
read all the safety warnings and operating instructions.
Unpack the heater carefully and retain the packaging for pos-
sible future use, in the event of moving or returning the fire to
your supplier.
Contents of Carton.
•
SP4 Heater.
•
Wall fixing bracket.
•
Six fixing screws and six wall plugs.
•
Remote control and batteries ( 3 AAA’s type).
•
Spare bulb.
Do not connect the heater to an electricity supply until it is
installed on a wall correctly. - see ‘Installation’.
When in operation there is a 300 watt heat output from the
fuel effect, and an additional 120 watt output when the heated
glass panel is in operation.
The heater can be used remotely or manually. - see ‘Opera-
tion’.
General features of remote control are:
•
Activate/Deactivate heated glass panel.
•
The illumination of fuel effect can be increased or
decreased.
•
Programmable timer.
Please note: Used in an environment where background noise
is very low, it may be possible to hear the motor which oper-
ates the flame effect. This is normal and should not be a cause
for concern.
General
Wall Fire SP4
Model No: SP420
