4.3 Configuration
4 Function description
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
4-4
4.3 Configuration 4300 Configuration 4- ][Funktionsbeschreibung_BA_Konfig Einf Ser
The module has the following configuration options:
 Interface parameter
 Threshold receive buffer
4.3.1 Interface parameters
Interface parameters 4- ][Funktionsbeschreibung_BA_Konfig Schnitt RS232 Ser
The following interface parameters can be configured:
 Transmission rate
 Block size (data bits and parity)
 Number of stop bits
 Continuous sending
 Xon/Xoff when sending
 Xon/Xoff when receiving
 RTS and CTS activated
4.3.2 Receive buffer threshold
Receive buffer threshold 4- ][Funktionsbeschreibung_BA_Konfig Schwell Ser
The number of Bytes in a receive buffer of the module is defined with this
value, from which the status bit "Receive buffer full" is set (default value:
512).
