Pilz PSSu H F PN o - Manual (Page 17)

Operation
Operating Manual PSSu H F PN o
1002522-EN-03
17
The module has two LEDs to display the device status ("ON" and "SO" LEDs).
X1
LNK
RX/TX
F0
X2
CHIP
F-ADDRESS
OFF ON
128
64
32
16
8
4
2
1
256
PROFINET
PSSu H
F PN o
PSSu H
F ON O
312 042
0000000
HW 000
ON
SO
SF
BF
0000
1111
2222
MAC
ADD
X1
X2
ON
SO
SF
BF
LED to display the device sta-
tus
Meaning
Name Status Colour
ON --- No supply voltage
Green Supply voltage present
Green Device is in PROFIenergy
mode
Red Error in the configuration or
hardware registry
Red Head module error
Or-
ange
Forcing
SO --- FS section is not running
Green FS section is running
Green Requires the user to confirm
via the reset button (e.g. after
swapping an FS module)
Flash-
es
green,
2 Hz
Head module is in PROFIsafe
test mode
