Woodhaven 4962: Taper Master User Manual

Additional hardware

background image

4962

Taper Master

Owners Manual

Please Read Carefully!

Part# Description Qty.
5760B Oval

Nut

7

Part# Description Qty.
HB030 1"

Bolt

1

Part# Description Qty.
MF006 5/8"

Screw 6

Part# Description Qty.
5863 Handle

3

Part# Description Qty.
BUSH001 1/8"

Spacer

3

Part# Description Qty.
BUSH002 1/4" Spacer

4

Part# Description Qty.
5590 Knob

1

Part# Description Qty.
BUSH004 5/8" Spacer

1

Additional Hardware:

Parts listed below are not shown in the hardware

drawings. Refer to photos in the instructions:

Part Description

Quantity

4962B MDF

Base

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

4962A

1/4" Fence Plates . . . . . . . . . . . . . . . . . . . . . . . . . 3

4436

36" Ultra Track Fence . . . . . . . . . . . . . . . . . . . . . 1

6305IC

Inboard Clamp . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

4918B

17-3/4" Jig Bars . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Part# Description Qty.
MF045 1"

Screw

6

Part# Description Qty.
NOB125 1-1/4"

Screw 1

Part# Description Qty.
NUT025 Square

Nut

3
