VERSATEC ULTRA SERIES INSTALLATION MANUAL
Compressor and Thermistor Resistance
Compressor Resistance Chart
Model
208-230/60/1
265/60/1
208-230/60/3
460/60/3
575/60/4
Run
Start
Run
Start
009
3.65 - 4.19
3.75 - 4.31
3.73 - 4.27
4.45 - 5.13
n/a
n/a
n/a
012
3.35 - 3.85
2.80 - 3.22
3.73 - 4.27
4.45 - 5.13
n/a
n/a
n/a
015
2.74 - 3.16
2.60 - 3.00
3.03 - 3.49
2.39 - 2.75
n/a
n/a
n/a
018
2.24 - 2.58
2.84 - 3.26
3.03 - 3.49
2.39 - 2.75
n/a
n/a
n/a
023-024
1.14 - 1.32
1.37 - 1.57
1.38 - 1.58
2.02 - 2.32
1.45 - 1.67
8.04 - 9.24
n/a
030
0.95 - 1.09
1.81 - 2.09
1.24 - 1.42
2.42 - 2.78
1.77 - 2.04
7.57 - 8.71
n/a
036
0.62 - 0.72
1.46 - 1.65
1.13 - 1.31
1.07 - 1.23
0.83 - 0.91
4.43 - 4.90
n/a
041-042
0.49 - 1.03
1.29 - 1.49
n/a
0.81 - 1.05
4.33 - 4.99
5.11 - 5.64
048
0.51 - 0.58
1.36 - 1.57
n/a
0.91 - 1.05
3.60 - 4.14
4.16 - 4.78
060
0.29 - 0.34
0.76 - 0.87
n/a
0.56 - 0.64
2.17 - 2.49
3.78 - 4.34
070
0.26 - 0.29
0.76 - 0.87
n/a
0.56 - 0.64
2.17 - 2.49
3.78 - 4.35
7/6/10
Thermistor Resistance Chart
Thermistor
Temperature (°F)
Microprocessor
Resistance (Ohms)
5
75757-70117
14
57392-53234
23
43865-40771
32
33809-31487
41
26269-24513
50
20570-19230
59
16226-15196
68
12889-12093
77
10310-9688
86
8300-7812
95
6723-6337
104
5480-5172
113
4490-4246
122
3700-3504
131
3067-2907
140
2554-2424
149
2149-2019
