22
VERSATEC ULTRA SERIES INSTALLATION MANUAL
Blower Performance Data
Standard PSC Motor
Optional High Static PSC Motor
Model
Blower
Spd
Blower
Size
Motor
hp
Airfl ow (cfm) at External Static Pressure (in. wg)
0 0.05 0.10 0.15 0.20 0.25 0.30 0.35 0.40 0.45 0.50 0.60 0.70 0.80 0.90 1.00
009
H
6 x 8 1/10
530 515 500 485 470 450 430 405 385 355 330 - - - - -
MH 475 460 450 435 420 405 385 365 345 320 300 - - - - -
ML* 435 420 410 395 380 365 345 325 300 - - - - - - -
L 370 355 340 325 310 290 275 - - - - - - - - -
012
H
6 x 8 1/10
530 515 500 485 470 450 430 405 385 355 330 - - - - -
MH* 475 460 450 435 420 405 385 365 345 320 300 - - - - -
ML 435 420 410 395 380 365 345 325 300 - - - - - - -
L 370 355 340 325 310 290 275 - - - - - - - - -
015
H
9 x 7 1/6
875 860 845 830 820 805 790 770 750 725 700 - - - - -
M 760 750 740 730 720 710 700 680 660 640 620 - - - - -
L 630 620 610 600 590 580 570 560 550 520 490 - - - - -
018
H
9 x 7 1/6
875 860 845 830 820 805 790 770 750 725 700 - - - - -
M 760 750 740 730 720 710 700 680 660 640 620 - - - - -
L 630 620 610 600 590 580 570 560 550 520 490 - - - - -
023
H
9 x 7 1/5
1020 990 960 930 900 870 850 830 800 770 690 - - - - -
M 960 840 820 800 780 760 740 720 690 670 - - - - - -
L 720 700 680 650 640 620 600 580 570 550 - - - - - -
024
H
9 x 7 1/5
1065 1045 1030 1005 975 950 925 900 870 835 800 - - - - -
M 880 865 850 830 815 795 775 750 725 700 670 - - - - -
L 805 790 780 765 745 725 710 685 660 630 600 - - - - -
030
H
9 x 7 1/3
1240 1220 1200 1175 1150 1110 1080 1055 1030 975 920 840 730 - - -
M 1095 1085 1080 1060 1045 1020 995 960 925 885 850 785 675 - - -
L 860 860 855 850 850 845 845 825 805 775 750 680 - - - -
036
H
9 x 7 1/2
1360 1340 1320 1290 1260 1220 1185 1130 1080 1045 1010 910 855 - - -
M 1205 1190 1170 1145 1120 1085 1050 1015 980 940 900 845 - - - -
L 1070 1060 1050 1035 1020 995 970 940 910 875 840 780 - - - -
041
H
10x10 1/2
1655 1635 1615 1590 1570 1535 1500 1425 1350 1270 1185 1080 970 - - -
M 1470 1455 1445 1425 1410 1380 1350 1285 1240 1205 1170 905 - - - -
L 1150 1140 1130 1110 1090 1050 1010 970 930 900 865 800 - - - -
042
H
10 x 10 1/2
1705 1685 1665 1645 1625 1595 1565 1530 1500 1450 1405 1260 1140 - - -
M 1485 1475 1465 1445 1430 1410 1390 1350 1315 1260 1210 1110 1010 - - -
L 1180 1165 1150 1135 1120 1090 1060 1030 1000 965 920 855 - - - -
048
H
10 x 10 1/2
1930 1910 1885 1860 1830 1790 1750 1710 1665 1620 1580 1280 1235 - - -
M 1580 1565 1550 1535 1525 1505 1485 1445 1410 1310 1215 1130 1030 - - -
L 1180 1170 1160 1140 1120 1100 1080 1050 1020 970 930 875 - - - -
060
H
11 x 10 1
2360 2330 2300 2270 2240 2215 2190 2160 2130 2095 2060 1985 1920 1855 - -
M 2165 2130 2095 2070 2050 2030 2010 1985 1965 1930 1900 1850 1775 1700 - -
L 1965 1940 1920 1900 1885 1870 1855 1825 1800 1780 1760 1720 1625 1530 - -
070
H
11 x 10 1
2450 2435 2420 2395 2370 2340 2310 2280 2250 2225 2200 2040 2000 1950 - -
M 2215 2190 2170 2155 2140 2120 2095 2070 2045 2015 1990 1940 1876 1795 - -
L 2005 1990 1975 1960 1950 1940 1925 1910 1890 1865 1845 1780 1710 1565 - -
7/6/10
Model
Blower
Spd
Blower
Size
Motor
hp
Airfl ow (cfm) at External Static Pressure (in. wg)
0 0.05 0.10 0.15 0.20 0.25 0.30 0.35 0.40 0.45 0.50 0.60 0.70 0.80 0.90 1.00
024
H
9 x 7 1/3
1240 1220 1200 1175 1150 1110 1080 1055 1030 975 920 840 730 - - -
M 1095 1085 1080 1060 1045 1020 995 960 925 885 850 785 675 - - -
L 860 860 855 850 850 845 845 825 805 775 750 680 - - - -
030
H
9 x 7 1/2
1340 1320 1300 1270 1240 1200 1160 1115 1070 1025 985 880 - - - -
M 1185 1175 1165 1130 1095 1065 1035 1000 965 920 880 795 - - - -
L 1050 1040 1030 1015 1000 980 960 925 895 855 815 - - - - -
042
H
10 x 10 3/4
2095 2080 2060 2020 1980 1950 1920 1880 1840 1780 1725 1550 1335 1120 - -
M 1960 1940 1920 1890 1865 1830 1800 1760 1725 1670 1620 1435 1300 - - -
L 1800 1780 1760 1740 1725 1695 1670 1625 1585 1525 1465 1300 1200 - - -
048
H
10 x 10 3/4
2095 2080 2060 2020 1980 1950 1920 1880 1840 1780 1725 1550 1335 1120 - -
M 1960 1940 1920 1890 1865 1830 1800 1760 1725 1670 1620 1435 1300 - - -
L 1800 1780 1760 1740 1725 1695 1670 1625 1585 1525 1465 1300 1200 - - -
7/6/10
Factory settings are in Bold
Airfl ow values are with dry coil and standard fi lter
For wet coil performance fi rst calculate the face velocity of the air coil (Face Velocity [fpm] = Airfl ow [cfm] / Face Area [sq ft]).
Then for velocities of 200 fpm reduce the static capability by 0.03 in. wg, 300 fpm by 0.08 in. wg, 400 fpm by 0.12in. wg. and 500 fpm by 0.16 in. wg.
Factory settings are in Bold
Airfl ow values are with dry coil and standard fi lter
For wet coil performance fi rst calculate the face velocity of the air coil (Face Velocity [fpm] = Airfl ow [cfm] / Face Area [sq ft]).
Then for velocities of 200 fpm reduce the static capability by 0.03 in. wg, 300 fpm by 0.08 in. wg, 400 fpm by 0.12in. wg. and 500 fpm by 0.16 in. wg.
* Setting for 265 V operation.
