46
VERSATEC ULTRA SERIES INSTALLATION MANUAL
Pressure Drop
Model gpm
Pressure Drop (psi)
30°F 50°F 70°F 90°F 110°F
009
1.5 2.0 1.7 1.4 1.3 1.0
2.0 3.8 3.2 2.8 2.3 1.8
3.0 7.2 6.0 5.1 4.5 4.0
4.0 12.0 10.0 9.0 7.5 6.0
012
1.5 1.1 1.0 0.9 0.8 0.7
2.5 2.5 2.3 2.1 1.8 1.5
3.5 3.9 3.6 3.2 2.7 2.3
4.5 5.3 4.9 4.5 3.8 3.5
015
2.0 0.6 0.5 0.5 0.4 0.4
3.0 1.1 1.0 0.9 0.8 0.6
4.0 1.9 1.8 1.6 1.5 1.3
5.0 3.3 3.2 3.0 2.9 2.7
018
3.0 1.1 1.0 0.9 0.8 0.6
4.0 1.9 1.8 1.6 1.5 1.3
5.0 3.3 3.2 3.0 2.9 2.7
6.0 4.5 4.4 4.3 4.1 4.0
023
3.0 1.1 1.0 0.9 0.8 0.6
4.5 2.4 2.2 2.1 2.0 1.9
6.0 4.5 4.4 4.3 4.1 4.0
8.0 6.7 6.6 6.5 6.3 6.2
024
3.0 1.1 1.0 0.9 0.8 0.6
4.5 2.4 2.2 2.1 2.0 1.9
6.0 4.5 4.4 4.3 4.1 4.0
8.0 6.7 6.6 6.5 6.3 6.2
030
4.0 0.9 0.8 0.7 0.6 0.5
6.0 1.9 1.8 1.7 1.6 1.5
8.0 3.7 3.6 3.5 3.4 3.3
10.0 4.8 4.7 4.6 4.5 4.4
036
5.0 1.4 1.1 0.9 0.7 0.5
7.0 2.5 2.3 2.1 1.8 1.6
9.0 6.0 5.8 5.5 5.3 5.1
12.0 6.6 6.4 6.2 6.0 5.7
041
5.0 1.5 1.2 0.9 0.5 0.4
8.0 3.4 3.1 2.8 2.5 2.1
11.0 7.9 7.5 7.2 6.9 6.6
14.0 9.1 8.8 8.5 8.2 7.9
042
5.0 1.5 1.2 0.9 0.5 0.4
8.0 3.4 3.1 2.8 2.5 2.1
11.0 7.9 7.5 7.2 6.9 6.6
14.0 9.1 8.8 8.5 8.2 7.9
048
6.0 2.0 1.7 1.3 1.0 0.6
9.0 4.2 3.8 3.5 3.1 2.7
12.0 6.7 6.3 5.9 5.6 5.2
16.0 11.5 11.2 10.8 10.5 10.1
060
9.0 3.6 3.3 3.0 2.7 2.3
12.0 6.1 5.8 5.5 5.2 4.8
15.0 9.6 9.2 8.9 8.6 8.3
20.0 15.5 15.2 14.9 14.5 14.2
070
12.0 4.1 3.6 3.2 2.8 2.3
15.0 5.9 5.0 4.6 4.1 3.7
18.0 8.8 8.4 7.9 0.5 7.1
24.0 12.9 12.0 11.5 11.1 10.7
7/6/10
Valve gpm Cv
Pressure
Drop (psi)
1/2 in.
1.5 9.6 0.02
2.0 9.7 0.04
3.0 9.9 0.09
4.0 10.1 0.16
1/2 in.
1.5 9.6 0.02
2.5 9.8 0.06
3.5 10.0 0.12
4.5 10.2 0.19
1/2 in.
2.0 9.7 0.04
3.0 9.9 0.09
4.0 10.1 0.16
5.0 10.4 0.23
1/2 in.
3.0 9.9 0.09
4.0 10.1 0.16
5.0 10.4 0.23
6.0 10.6 0.32
3/4 in.
3.0 9.9 0.09
4.5 10.2 0.19
6.0 10.6 0.32
8.0 11.0 0.53
3/4 in.
3.0 9.9 0.09
4.5 10.2 0.19
6.0 10.6 0.32
8.0 11.0 0.53
3/4 in.
4.0 10.1 0.16
6.0 10.6 0.32
8.0 11.0 0.53
10.0 11.5 0.76
3/4 in.
5.0 10.4 0.23
7.0 10.8 0.42
9.0 11.2 0.64
12.0 11.9 1.02
3/4 in.
5.0 10.4 0.23
8.0 11.0 0.53
11.0 11.7 0.89
14.0 12.3 1.29
1 in.
5.0 15.9 0.10
8.0 16.6 0.23
11.0 17.2 0.41
14.0 17.9 0.61
1 in.
6.0 16.1 0.14
9.0 16.8 0.29
12.0 17.4 0.47
16.0 18.3 0.76
1 in.
9.0 16.8 0.29
12.0 17.4 0.47
15.0 18.1 0.69
20.0 19.2 1.09
1 in.
12.0 17.4 0.47
15.0 18.1 0.69
18.0 18.7 0.92
24.0 20.1 1.43
11/10/09
