VERSATEC ULTRA SERIES INSTALLATION MANUAL
Electrical Data
PSC Motor
HACR circuit breaker in USA only
* With optional high-static PSC motor
** With optional IntelliStart
TM
NOTE: High-static option not available on all model sizes.
Model
Rated
Voltage
Voltage
Min/Max
Compressor Blower
Motor
FLA
Total
Unit
FLA
Min
Circ
Amp
Max
Fuse/
HACR
MCC RLA LRA LRA**
009
208-230/60/1 187/253 6.4 4.1 21.0 n/a 0.6 4.7 5.7 10/15
265/60/1 238/292 6.7 4.3 22.0 n/a 0.6 4.9 6.0 10/15
012
208-230/60/1 187/253 7.7 4.9 25.0 n/a 0.6 5.5 6.7 10/15
265/60/1 238/292 7.0 4.5 22.0 n/a 0.6 5.1 6.2 10/15
015
208-230/60/1 187/253 9.2 5.9 29.0 n/a 1.1 7.0 8.5 10/15
265/60/1 238/292 7.8 5.0 28.0 n/a 1.0 6.0 7.2 10/15
018
208-230/60/1 187/253 10.4 6.7 33.5 13.4 1.1 7.8 9.5 15
265/60/1 238/292 8.7 5.6 28.0 n/a 1.0 6.6 8.0 10/15
023
208-230/60/1 187/253 21.0 13.5 58.3 23.3 1.2 14.7 18.1 30
265/60/1 238/292 14.0 9.0 54.0 n/a 1.1 10.1 12.4 20
208-230/60/3 187/253 11.0 7.1 55.0 33.0 1.2 8.3 10.1 15
460/60/3 414/506 5.5 3.5 28.0 16.8 0.6 4.1 5.0 10/15
024
208-230/60/1 187/253 21.0 13.5 58.3 23.3 1.2 14.7 18.1 30
265/60/1 238/292 14.0 9.0 54.0 n/a 1.1 10.1 12.4 20
208-230/60/3 187/253 11.0 7.1 55.0 33.0 1.2 8.3 10.1 15
460/60/3 414/506 5.5 3.5 28.0 16.8 0.6 4.1 5.0 10/15
024*
208-230/60/1 187/253 21.0 13.5 58.3 23.3 1.5 15.0 18.4 30
265/60/1 238/292 14.0 9.0 54.0 n/a 1.5 10.5 12.8 20
208-230/60/3 187/253 11.0 7.1 55.0 33.0 1.5 8.6 10.4 15
460/60/3 414/506 5.5 3.5 28.0 16.8 1.0 4.5 5.4 10/15
030
208-230/60/1 187/253 22.0 14.1 73.0 29.2 1.5 15.6 19.1 30
265/60/1 238/292 17.5 11.2 60.0 n/a 1.5 12.7 15.5 25
208-230/60/3 187/253 13.9 8.9 58.0 34.8 1.5 10.4 12.6 20
460/60/3 414/506 6.5 4.2 28.0 16.8 1.0 5.2 6.3 10/15
030*
208-230/60/1 187/253 22.0 14.1 73.0 29.2 2.2 16.3 19.8 30
265/60/1 238/292 17.5 11.2 60.0 n/a 2.0 13.2 16.0 25
208-230/60/3 187/253 13.9 8.9 58.0 34.8 2.2 11.1 13.3 20
460/60/3 414/506 6.5 4.2 28.0 16.8 1.1 5.3 6.4 10/15
036
208-230/60/1 187/253 27.0 17.3 96.7 38.7 2.2 19.5 23.8 40
265/60/1 238/292 19.0 12.2 72.0 n/a 1.1 13.3 16.3 20
208-230/60/3 187/253 20.0 12.8 95.0 57.0 2.2 15.0 18.2 30
460/60/3 414/506 10.0 6.4 45.0 27.0 1.1 7.5 9.1 15
041
208-230/60/1 187/253 31.0 20.0 115.0 46.0 3.5 23.5 28.5 45
208-230/60/3 187/253 20.0 12.8 95.0 57.0 3.5 16.3 19.5 30
460/60/3 414/506 10.0 6.4 45.0 27.0 1.8 8.2 9.8 15
575/60/3 517/633 8.5 5.4 38.0 n/a 1.4 6.8 8.2 10/15
042
208-230/60/1 187/253 31.0 20.0 115.0 46.0 3.5 23.5 28.5 45
208-230/60/3 187/253 20.0 12.8 95.0 57.0 3.5 16.3 19.5 30
460/60/3 414/506 10.0 6.4 45.0 27.0 1.8 8.2 9.8 15
575/60/3 517/633 8.5 5.4 38.0 n/a 1.4 6.8 8.2 10/15
042*
208-230/60/1 187/253 31.0 20.0 115.0 46.0 4.6 24.6 29.6 45
208-230/60/3 187/253 20.0 12.8 95.0 57.0 4.6 17.4 20.6 30
460/60/3 414/506 10.0 6.4 45.0 27.0 2.3 8.7 10.3 15
575/60/3 517/633 8.5 5.4 38.0 n/a 1.9 7.3 8.7 10/15
048
208-230/60/1 187/253 32.0 21.0 115.0 46.0 3.5 24.5 29.8 50
208-230/60/3 187/253 25.0 16.0 115.0 69.0 3.5 19.5 23.5 35
460/60/3 414/506 12.0 7.7 50.0 30.0 1.8 9.5 11.4 15
048*
208-230/60/1 187/253 32.0 21.0 115.0 46.0 4.6 25.6 30.9 50
208-230/60/3 187/253 25.0 16.0 115.0 69.0 4.6 20.6 24.6 40
460/60/3 414/506 12.0 7.7 50.0 30.0 2.3 10.0 11.9 15
575/60/3 517/633 10.0 6.4 40.0 n/a 1.9 8.3 9.9 15
060
208-230/60/1 187/253 41.0 26.3 150.0 60.0 5.9 32.3 38.8 60
208-230/60/3 187/253 27.5 17.6 120.0 72.0 5.9 23.5 27.9 45
460/60/3 414/506 13.0 8.3 70.0 42.0 3.0 11.3 13.4 20
575/60/3 517/633 11.5 7.4 53.0 n/a 1.9 9.3 11.2 15
070
208-230/60/1 187/253 47.0 30.1 145.0 58.0 5.9 36.0 43.5 70
208-230/60/3 187/253 28.0 17.3 120.0 72.0 5.9 23.2 27.5 40
460/60/3 414/506 15.0 9.6 70.0 42.0 3.0 12.6 15.0 20
575/60/3 517/633 12.5 8.0 53.0 n/a 1.9 9.9 11.9 15
05/21/13
