1. SURGE + DIAGNOSTIC PRODUCT OVERVIEW
The Surge + Diagnostic is a state-of-the-art, microprocessor-controlled, power protector and conditioner with real-
time data acquisition and storage.
Models: This manual applies to the following Surge + Diagnostic models:
Key Features:
 Normal and Common Mode EMI Noise Filter
 Multi-Stage Normal and Common Mode AC Surge Protection
 Zero-Voltage Turn-On
 Zero- Current Turn-Off
 Inrush Current Elimination (ICE ® )
 Wiring Fault Detection
 Catastrophic Over/Under Voltage Shutdown (CouVS ® ) with selectable thresholds
 Under-Voltage Event Recorder (up to 999 events)
 Over-Voltage Event Recorder (up to 999 events)
 Power Outage Event Recorder (up to 999 events)
 Surge Event Recorder (up to 999 events)
o Records surges in all three modes: Line-Neutral, Line-Ground, Neutral-Ground (120V)
o Records surges in all three modes: Line1-Line 2, Line1-Ground, Line2-Ground (120/230V)
 Event Timestamp Recorder (up to 60 events)
o Records time between events
 LCD Event Monitor cycles through:
o Under-Voltage Events
o Over-Voltage Events
o Power Outage Events
o Surge Events
o Last Recorded Event Type
o Output Status (On or Off)
o Additional information in certain circumstances
(detailed in Section 3.1: Hardware/
LCD Event Monitor)
 Additional features available when connected to a PC
(detailed in Section 4: Diagnostic Software)
Technical Support:
 To download software and access further product information, visit www.surgex.com
 For technical support, please contact SurgeX at 1-800-645-9721
Model Number Voltage (AC RMS) Current (AC Amps) LCD Outlet Size
SX-HS-15-R 120 15 Yes
x 8
1 RU
SX-HS-20-R 120 20 Yes
x6 x2
1 RU
SX-HS-L530-R 120 30 No
x 1
2 RU
SX-HS-L630-R 120/230 Split Phase 30 Yes
x 1
2 RU
SX-HS-L630-RDB 120/230 Split Phase 2 x 30 Yes
x 2
2 RU
