6. SPECIFICATIONS
Parameter Specification
Load Rating SX-HS-15-R 15 Amps at 120 Volts
SX-HS-20-R 20 Amps at 120 Volts
SX-HS-L530-R 30 Amps at 120 Volts
SX-HS-L630-R 30 Amps at 120/230 Volts Split Phase
SX-HS-L630-RDB 2 x 30 Amps at 120/230 Volts Split Phase
Voltage Protection Rating
(VPR) SX-HS-15-R
SX-HS-20-R 330V All Modes
SX-HS-L530-R Pending
SX-HS-L630-R
SX-HS-L630-RDB 800V Line-Line
500V Line-Ground
Attenuation Normal
Mode SX-HS-15-R
SX-HS-20-R
SX-HS-L530-R
SX-HS-L630-R
SX-HS-L630-RDB > 30 dB 80kHz – 50MHz
Common
Mode
SX-HS-15-R
SX-HS-20-R
SX-HS-L530-R > 30 dB 70kHz – 50MHz
SX-HS-L630-R
SX-HS-L630-RDB > 30 dB 200 kHz – 50MHz
Power Requirement
(no load)
SX-HS-15-R
SX-HS-20-R 4 Watts
SX-HS-L530-R
SX-HS-L630-R
SX-HS-L630-RDB
6 Watts
Under-Voltage Shutdown 120V Models Adjustable from 80V to 95 V, or Disabled. Restores at 105V.
208/230V Models Adjustable from 140V to 170 V, or Disabled. Restores at 190V.
Over-Voltage Shutdown 120V Models Adjustable from 135V to 160V. Restores at 130V.
208/230V Models Adjustable from 260V to 300V. Restores at 250V.
Internal Memory Capacity 60 Events with timestamp; 999 counts of each event type
Timestamp Accuracy ± 2.5%
Voltmeter Accuracy
(Peak Reading Type) 120V Models ± 2% Typical product accuracy between 40V and 180V
208/230V Models ± 2% Typical product accuracy between 100V and 300V
Response Time Over-Voltage 100 msec
Under-Voltage 150 msec
Under-Voltage Record
Definition 120V Models AC Voltage has dropped below 100V
208/230V Models AC Voltage has dropped below 180V
Over-Voltage Record
Definition 120V Models AC Voltage has risen above 135V
208/230V Models AC Voltage has risen above 260V
Power Outage Event Definition AC Voltage has dropped below 20V
Surge Event Definition Surge + Diagnostic has been exposed to a transient voltage in one of the 3 possible
modes (between Live and Neutral, between Live and Ground, between Neutral and
Ground) with a peak amplitude of 500V-700V* or higher and a frequency of 20 kHz or
higher. *500V-700V surge voltage amplitude applies to IEEE C62.41 Category B
Impulse; surge voltage amplitudes necessary for detection of other surge types may
vary.
