CM-1115(20)-RT-AR User Manual Page 30
XI. Specifications
Physical
Width Depth Height Weight # Outlets
CM-1115(20)-RT-AR 4.95" 9.50" 6.16" 9lb. 2
Temperatue 5 - 35° C
Humidity Range 5% to 95% R.H., non-condensing
AC
Load Rating
CM-1115-RT-AR 15 Amps @ 120 Volts (1800W)
CM-1120-RT-AR 20 Amps @ 120 Volts (2400W)
Power Requirement (no load) 10 Watts
UL 1449-2 Adjunct Classification Test Results
1000 surges, 6000 Volts, 3000 Amps,C1 pulse, measured
suppressed voltage 290 Volts, no failures
Maximum Applied Surge Pulse Joule Rating Unlimited, due to current limiting (8 x 20 µs)
Maximum Applied Surge Pulse Voltage 6000 volts (1.2 x 50 µs pulse),industry standard rating
Maximum Applied Surge Pulse Current Unlimited, due to current limiting (8 x 20 µs)*
Endurance IEEE C62.41-1991 Category B3 (C1)
Pulses 1 kV>500,000; 3 kV>10,000; 6 kV>1000
Over-Voltage Shutdown 145 Volts (resume at 135 Volts)
Under-Voltage Shutdown 90 Volts (resume at 100 Volts)
Maximum Load Inrush Energy 1000 Joules total during power-up
EMI/RFI Filter
Normal Mode (50 Ω
load)
40 dB@100 kHz;50 dB@300 kHz;50 dB@3 MHz;50 dB@30 MHz
Common Mode (50 Ω
load)
18 dB@300 kHz; 30 dB@1 MHz;50 dB@5 MHz; 50 dB@20 MHz
Remote Connections
Remote Control Voltage
5 – 30VDC
Remote Control Current Draw 4mA maximum
Contact Closure Max. Resistance
100 Ω
Auxiliary Relay Contact Rating 30VDC @ 1A
12V Output Max. Current 20mA
Network
Single 10/100 Unshielded Twisted Pair Ethernet Jack
IP Addressed: DHCP Assigned or Static
Internal HTTP Web Server
Forms Processing Browser Required
Internal Telnet Server
Compliance
UL/cUL
UL60950 Listed I.T.E.
File No. E225914
UL 1449 3rd Edition In Progress
CE Directives 89/336/EEC, 92/31/EEC and 93/68/EEC
EN 60950: 3rd Edition
EN55022: 1998 Class B
FCC Part 15 Class B
*1.2 x 50 µs pulse, industry standard combination wave surge, as per IEEE C62.41
CAUTION: Do not install this device if there is not at least 10 meters (30 feet) or more between the
electrical outlet and the electrical service panel.
