CM-1115(20)-RT-AR User Manual
Page 9
V. Initial Set-Up
(continued)
Manage
Open Browser: Opens the web browser interface for the selected AR.
Upgrade Firmware: Starts the Firmware Upgrade dialogue
Firmware Upgrade Requirements
Valid firmware file.
Administrative login credentials.
“Upgrade Enable” must be set to yet, set via web page or CLI
Set
IP Address: Changes the IP address of the selected AR
Factory Defaults: Return the selected AR to a Factory Default state. This action
must be performed within the first 2 minutes after powering up the unit.
Local Address: Select the IP address to Discover on. This may be necessary for
computers with multiple network connections.
Exit
Exits the DMU program.
Help
Online Help: Opens a web browser to online help resources.
About: Displays DMU version information.
Setting the IP Address
ARs are configured with a factory default IP address of 192.168.1.254.
To set the AR’s IP address using one of the following methods, the computer and AR must be on
the same local network.
DMU: Follow the steps in the preceding subsection to set the IP address using the Device
Management Utility (DMU).
CLI: These are the basic commands to set the network parameters. After setting these
parameters, the AR will need to be rebooted for the settings to take effect. Any command that
requires rebooting of the AR will provide a prompt to do so. All commands may be entered as
required before rebooting. Manually specifying the IP address via CLI automatically sets the
address as static.
