CM-1115(20)-RT-AR User Manual Page 27
VIII. DxP Protocol
(continued)
Payloads
TChangeRelay
typedef struct{
unsigned char relay;
unsigned char state;
} TChangeRelay;
Where relay is the number of the relay to be affected – 1 (For example, 0 for relay 1 and 1
for relay 2) and state sets the state of the relay (1=Energize; 2=Relax).
TChangeRelays
typedef struct{
unsigned char relayStates[32];
}TChangeRelays;
Where relayStates is an array of relay states as defined below:
#define NO_CHANGE 0
#define ENERGIZE 1
#define RELAX
2
This payload is supported by devices that support the DxP protocol with 2-32
controllable relays.
TPulseRelay
typedef struct{
unsigned char relay; //the relay to be pulsed
unsigned char state; //the state to pulse
uint16 pulseWidth; //the pulse width in seconds
}TPulseRelay;
Where relay is the number of the relay to be affected, state is the state to pulse,
and pulseWidth is the time to pulse in seconds.
