FLANGER Pages
Flanging involves splitting the input signal into at least two individual delayed
signals (here referred to as Voice 1 and Voice 2), then modulating these delayed signals
so that, when summed back together with the direct signal, phase cancellations will
occur at some frequencies while peaks in the response will occur at others.
Flanger Page 1: Voice 1
122
D
ESCRIPTION
The FLANGE parameter determines whether the flanger is active for the current
preset. (Off, On)
The LEVEL1 parameter determines the volume of Voice 1 relative to Voice 2. (Off
to +6.0)
The PAN1 parameter allows you to pan Voice 1 to the left or right channel. (Left
to Right)
The DEPTH 1 parameter adjusts the amount of modulation of Voice 1. Lower
DEPTH settings produce more subtle effects, while higher settings will result in a
more drastic effect. (0 to 100)
The RATE 1 parameter determines the speed at which Voice 1 is modulated. (0 to
253)
P
ARAMETER
FLANGE
LVL1
PAN1
DPTH1
RATE1
Flanger Page 1 parameters
FLANGE
ON
LVL1
+ 3.0
PAN1
L<30
RATE1
100
DPTH1
70
