8-2 Simple troubleshooting for Inverter

Error message

displayed

Error description

Troubleshooting

Output over-voltage

(1)Ol-3320 detects circuit error

Replace Ol-3320

(2)Ol-3300 feedbacks circuit error

Replace Ol-3300

(3)Ol-3300 program parameter is too high

Correct Program

Parameter

(4)Ol-3300controlerror

Replace

Ol-3300

Output under-voltage

(1)Ol-3320 detects circuit error

Replace Ol-3320

(2)Ol-3300 feedbacks circuit error

Replace Ol-3300

(3)Ol-3300program parameter is too low

Correct Program

Parameter

(4)Ol-3300controlerror

Replace

Ol-3300

Output over-current

(1)Load exceeds 100% above

Unload Load To Under

100%

(2)Ol-3316 detects circuit error

Replace Ol-3316

(3)Ol-3300 program parameter is too high

Correct Program

Parameter

Inverter input

over-current

There isn’t a function like this for now

Temperature on the

Inverter is too high

(1)Temperature of heat sink sheet on

inverter side is too high

Unload Load To Below

100%

(2)Temperature switch line is open

Recover Temperature

Switch Line

(3)Error on receiving ol-3312 signal

Replace Ol-3312

(4)Error on receiving ol-3300 signal

Replace Ol-3300

VCE Fault

(1)IGBT component short circuit

Replace IGBT

Component

(2)Output is short circuit

Eliminate Short Circuit

(3)Error on IGBT signal line connection

method

Recover IGBT Signal

Line Connection Method

(4)Ol-3312 control error

Replace Ol-3312

(5)Ol-3300 control error

Replace Ol-3300
