8 DS-C33 Series troubleshooting

8-1 Simple troubleshooting chart

Error message displayed

Error description

Troubleshooting

Input over-voltage

(1)Utility voltage is too high

Recover utility to +/-20% or

below

(2)Ol-3320 detects circuit error

Replace ol-3320

(3)Ol-3300 feedbacks circuit error

Replace ol-3300

(4)Ol-3300 program parameter is

too high

Correct program parameter

Input under-voltage

(1)Utility voltage is too low

Recover utility to +/-20% or

below

(2)Ol-3320 detects circuit error

Replace ol-3320

(3)Ol-3300 feedbacks circuit error

Replace ol-3300

(4)Ol-3300program parameter is too

low

Correct program parameter

Input over-current

(1)Load is over for 125% above

Unload to 100% below

(2)Ol-3316 feedbacks circuit error

Replace ol-3320

(3)Ol-3300program parameter is too

high

Correct program parameter

(4)SCR component damaged

Replace SCR component

(5)Ol-3302 trigger signal to SCR is

abnormal

Replace ol-3302

(6)Ol-3302controlerror

Replace

ol-3302

Input frequency is too high (1)Utility frequency is too high

Recover frequency to +/-3Hz

(2)Ol-3320 detects circuit error

Replace ol-3320

(3)Error on ol-3300 zero point

detects circuit

Replace ol-3300

(4)Error on ol-3300program

diagnose

Replace program

Input frequency is to low (1)Utility frequency is too low

Recover frequency to +/-3Hz

(2)Ol-3320 detects circuit error

Replace ol-3320

(3)Error on ol-3300 zero point

detects circuit

Replace ol-3300

(4)Error on ol-3300 program

diagnose

Replace program
