background image

will be installed.

4-2 Installation

4-2-1 Input / Output Specifications

System output 50Hz/60Hz 3 wire 3 phase wire 200Vac, 220Vac 50Hz/60Hz 3 phase 4 wire and

grounding wire 110/190Vac,115/200Vac,120/208Vac,127/220Vac 220/380Vac,230/400Vac,240/415Vac

System output 50Hz/60Hz 3 phase 4 wire and grounding wire 110/190Vac, 115/200Vac, 120/208Vac,

127/220Vac, 220/380Vac, 230/400Vac, 240/415Vac. The table below shows the UPS input/output

current and switch specifications.

Rating Voltage Input

max.

current

Input circuit

breaker

Out max

current

Output

circuit

breaker

Neutral wire

max. current

110/190V 55A 3P/60A 38A 3P/50A 65A

120/208V 49A 3P/50A 35A 3P/40A 60A

10KVA

220/380V 28A 3P/30A 19A 3P/20A 32A

110/190V 82A 3P/100A 57A 3P/75A 98A

120/208V 74A 3P/75A 52A 3P/60A 90A

15KVA

220/380V 39A 3P/40A 28A 3P/30A 48A

110/190V 122A 3P/125A 85A 3P/100A 147A

120/208V 114A 3P/125A 78A 3P/80A 135A

22.5KVA

220/380V 62A 3P/80A 43A 3P/60A 74A

110/190V 163A 3P/175A 113A 3P/125A 195A

120/208V 149A 3P/150A 104A 3P/125A 180A

30KVA

220/380V 83A 3P/100A 57A 3P/75A 98A

110/190V 239A 3P/300A 170A 3P/200A 294A

120/208V 223A 3P/225A 156A 3P/150A 270A

45KVA

220/380V 121A 3P/125A 85A 3P/100A 147A

110/190V 312A 3P/350A 226A 3P/225A 391A

120/208V 290A 3P/300A 208A 3P/225A 360A

60KVA

220/380V 158A 3P/175A 114A 3P/125A 197A

80KVA 220/380V

211A

3P/225A

149A

3P/150A

263A

100KVA 220/380V

242A

3P/300A

189A

3P/200A

327A

120KVA 220/380V

291A

3P/300A

227A

3P/225A

393A

150KVA 220/380V

364A

3P/400A

284A

3P/300A

491A

200KVA 220/380V

485A

3P/500A

378A

3P/400A

654A

250KVA 220/380V

598A

3P/600A

473A

3P/500A

819A
