4-2-3 Input/Output connection and precaution

From table 4-2-1 and table 4-2-2, we could determine the installation wire diameter and breaker

capacity, as shown below.

Rating

Mains voltage

Input circuit

breaker

Input wire

diameter (mm

2

)

Output circuit

breaker

Output wire

diameter (mm

2

)

110/190V

3P/60A

14

3P/50A

14

120/208V

3P/50A

14

3P/40A

14

10KVA

220/380V

3P/30A

5.5

3P/20A

5.5

110/190V

3P/100A

22

3P/75A

14

120/208V

3P/75A

22

3P/60A

14

15KVA

220/380V

3P/40A

8

3P/30A

8

110/190V

3P/125A

38

3P/100A

22

120/208V

3P/125A

38

3P/80A

22

22.5KVA

220/380V

3P/80A

22

3P/60A

14

110/190V

3P/175A

50

3P/125A

38

120/208V

3P/150A

50

3P/125A

38

30KVA

220/380V

3P/100A

22

3P/75A

22

110/190V

3P/300A

100

3P/200A

60

120/208V

3P/225A

60

3P/150A

38

45KVA

220/380V

3P/125A

38

3P/100A

22

110/190V

3P/350A

125

3P/225A

60

120/208V

3P/300A

100

3P/225A

60

60KVA

220/380V

3P/175A

60

3P/125A

38

80KVA 220/380V

3P/225A

60

3P/150A

38

100KVA 220/380V

3P/300A

150

3P/200A

60

120KVA

220/380V

3P/300A 150 3P/250A 80

150KVA

220/380V

3P/400A 200 3P/300A 150

200KVA

220/380V

3P/500A 225 3P/400A 200

250KVA

220/380V

3P/600A 250 3P/500A 225

Tab. 4-2-3
