Voltage of DC chain

voltage is too high

(1)Ol-3302DCvoltage feedbacks

point open circuit

Recover feedbacks circuit

(2)Ol-3302 feedbacks circuit error

Replace ol-3302

(3)Ol-3300program parameter is too

high

Correct program parameter

(4)SCR component short circuit

Replace SCR component

(5)Error on ol-3302 control

Replace ol-3302

Voltage of DC chain

voltage is too low

(1)Ol-3302DCvoltage feedbacks

point open circuit

Recover feedbacks circuit

(2)Ol-3302 feedbacks circuit error

Relaceol-3302

(3)Parameter of ol-3300 program is

too low

Correct program parameter

(4)Battery power is insufficient and

utility voltage is too low

Recover utility to +/-20% or

below

(5)IGBT component short circuit

Replace IGBT component

(6)Ol-3302 control error

Replace ol-3302

Recharge current is too

high

(1)Ol-3302 recharge current

exceeds limit current point

Replace ol-3302

(2)Ol-3302 feedbacks circuit error

Replace ol-3302

(3)Ol-3300 program parameter is

too high

Replace ol-3300

(4)Error on ol-3302 control

Replace ol-3302

(5)Battery is not function well

replace battery

Temperature of recharge

machine is too high

(1)Temperature of side heat sink

sheet on recharge machine is too

high

Unload to under 100% load

(2)Temperature switch line is open

Recover temperature switch line

(3)Error on ol-3302 receiving signal

Replace ol-3302

(4)Error on ol-3300 receiving signal

Replace ol-3300

Input phase sequence error

(1)Phase sequence of input power is

reverse

Recover input power to positive

phase sequence

(2)Ol-3320 feedbacks circuit error

Replace ol-3302

(3)Error on ol-3302 CPLD signal

Replace ol-3302

(4)Error on ol-3300 receive signal

Replace ol-3302
