4 Placement and installation

4-1 Placement

4-1-1 Transporting

The UPS system is composed of the main equipment and battery pack. Therefore be careful when

transporting it and handle it following the points listed below.

(1) Follow the arrow symbol in the carton for the correct position of the UPS. Don’t turn it upside

down or in a slanting position.

(2) It is necessary to fasten the system firmly during transportation.

(3) When transporting, don’t remove the packaging to reduce impact to the system.

(4) When transporting, make sure that the unit does not get wet.

(5) Do not drop and avoid strong impacts to this UPS to protect the components from damage.

4-1-2 Unpacking

Please follow the steps below to unpack the UPS.

(1) Cut the wrapping and remove the packing board.

(2) Remove PE cubicle for protecting the equipment.

(3) Unscrew UPS from the pallet base.

(4) Put a ramp board at the back of the UPS, and let it slide down smoothly.

4-1-3 Position and Environment:

Precaution for storage

(1) Ambient temperature of installation site range form +28℃ to -10℃. Battery life will be

reduced if the ambient temperature exceeds this range. Ideal ambient temperature for operating

the equipment is between +25℃ and 5℃.

(2) Sufficient space must be provided around the equipment to enable maintenance operations. A

space of 1M must be available in front of the equipment and minimum 50cm of space around

the UPS for ventilation.

(3) Table 4-1-3 shows the BTU consumption for DS-33 series.

Model BTU Model BTU

DS10KC33 4819

DS60KC33 28909

DS15KC33 7225

DS80KC33 38546

DS22.5KC33 10841

DS100KC33 48183

DS30KC33 14454

DS120KC33

32640

DS45KC33 21682

Table 4-1-3

(4) It is essential to have sufficient illumination and fire control device in the room where the UPS
