Table 4-2-1

When installing the UPS, please refer to table of 4-2-1 for corresponding input/output circuit breaker.

Refer to table 4-2-2 for wire specifications and capacity

Insulating Wire

Acceptable highest temperature of insulating

materials

1 PVC

wire

2 RB

wire

60℃

3 Heatproof PVC wire

4 PE

Wire

75℃

5 SBR

Wire

6 Artificial rubber wire

80℃

7 EP rubber wire

8 Cross connect PE wire

90℃

Ampere capacity for every kind wire(ambient temperature 35℃)

Copper

conducting wire

60℃insulation 75℃insulation

80℃insulation 90℃insulation

wire

SWG AWG

number

diameter

Ampere capacity (A)

2.0 14 7/0.6

20

3.5 12 7/0.8

30

5.5 10 7/1.0

40

8 8 7/1.2

55

65

70

80

14 6 7/1.6

80

95

100

110

22 4 7/2.0

100

125

135

145

30 7/2.3

125

150

160

170

38 2 7/2.6

145

180

190

205

50 19/1.8

175

210

220

245

60 0 19/2.0

200

240

250

280

80 19/2.3

230

285 300 330

100 19/2.6

270 330 350 380

125 19/2.9

310 380 400 440

150 37/2.3

360 440 460 505

200 37/2.6

425 520 550 600

250 61/2.3

505 615 650 710

325 61/2.6

590 720 760 830

400 61/2.9

680 825 870 995

Wiring

500

61/3.2 765

930

985

1080
