SPECIFICATIONS
80
Problem
• Leak around the cap of the urine tank.
Solution
• The system is over-pressurized. Insert a catheter and drain
the urine system. Remove the catheter and fill the urine
system with 100ml of air. Insert catheter and drain the
urine system. Remove catheter. Repeat until all the fluid has
drained out of the urine tank and only air exits the catheter.
Follow the filling procedure and fill the urine system. Make
sure that there are no leaks around the cap of the urine
tank. If it is still leaking, the urine tank needs to be replaced.
Problem
• Difficult to insert a catheter
Solution
• The system is over-pressurized. Insert a catheter and drain
the urine system. Remove catheter. Empty the urine tank by
filling the urine system with 100ml of air. Insert catheter and
drain the urine system. Remove catheter. Repeat until all
the fluid has drained out of the urine tank and only air exits
the catheter.
If catheter cannot be inserted, disconnect genitalia from
urine system. See Changing Genitalia Modules. Insert
catheter into genitalia, and re-connect to the urine tank.
Fluid will exit the catheter immediately.
Main Specifications
Size, weight
Dimensions (manikin only):
1800mm (l) x 550mm (b) chest
(5.90 ft x 1.80 ft)
Weight (patient manikin only): 38,5kg (85 lbs)
Weight (with clothes)
40 Kg (88 lbs)
Manikin power
External power:
Input voltage 24VDC, 6.25A
Internal batteries (two):
Each 14.8V, 4.6Ah, Lithium-Ion
Only use the SimMan Essential external power supply and
batteries.
air & co
2
Pressure
Internal fluid reservoir:
Max 0.9 bar
External air connection:
Max 1.4 bar
External CO
2
to manikin:
Max 1.4 bar
temperature limits
Operating temperatures:
+4 ºC to 40 ºC (39 ºF to 104 ºF)
Storage temperatures*:
-15 ºC to 50 ºC (5 ºF to 122 ºF)
* Requires that the fluid tanks and system is filled with 60%
Isopropanol or 70% EtOH
environment - Manikin only
Relative humidity: 20% -90% (non-condensing)
DO NOT use outdoors in wet conditions.
Not tested with salt spray.
rf communication
WLAN frequency ranges:
2.4 GHz WLAN, channels 1-11.
5 GHz WLAN, channels 36 - 64,149 - 165.
Operation range: 100 m (300 ft) max.
Material chart for Manikin
Clothes:
Cotton, Nylon
Skins and airways PVC (DEHP free)
External hard plastics: PP, PA, PC, PC/PET
Inner plastics:
Silicone, TPU, TPE, PVC, Nitrile
PA, PA+GF, PC, ABS, POM, HDPE, PET,
Epoxy-Polyurethane
Metal components: Aluminum, Brass, Steel
Minimum hardware requirements for use
with SimMan essential tablet Pc’s)
• Core 2 Duo or better
• 1 GB RAM (2 GB recommended)
• 1GB hard disk space,
• 1024x768, 1280x800, 1280x1024 or better
• 16bit color resolution or better
• 100% DPI required
• Optical drive required for installation
Minimum Software requirements
• Windows XP or Windows 7
• DotNet 3.5.1
