3-3
OPERATING PROCEDURE
3.2 INSTRUMENT IDENTIFICATION
During the warm-up cycle, the instrument display identifies
the model, serial number, software version and battery
status information as shown in Fig. 3.2:
Fig. 3.2 Instrument Identification
3.3 BATTERY STATUS
This feature provides the user with a battery capacity
level indicator that displays instrument battery power
remaining, as shown in Fig. 3.3.
100%
75%
50%
25%
Fig. 3.3 Battery Capacity
This battery symbol will be indicated for approximately
five (5) seconds during the warm-up cycle, then on the
top of the display during normal operation.
