HSM-I-08-08
10
If neither the VID nor the AUD button is on, the following screens will be displayed and
alternated every 3 seconds.
To turn the Matrix off, press and hold the power button for 3 seconds. This is done as a
precaution, so that if the power button is accidentally touched, it will not turn off the
matrix! When the Matrix is off, the following screens will be shown on the LCD.
3.3 Making AV Routings or “Ties” from Front Panel
To make the unit as convenient and intuitive as possible the HSM matrix allows you to
make ties starting from the input channel’s point of view or from the output.
3.3.1 Making a tie starting from the output
This is the most natural way of making connections since each output gets is signal
from only one input.
 Press one of the output channel buttons. That output button will light up
along with an input button it is being routed from.
 If you do not want to make any changes, just hit SET. If you want to change
to another output channel, use either the up and down (▲▼) buttons to walk
through other outputs; or just select another output channel. The up and
down (▲▼) buttons can also be pressed and held to quickly view all output
channels one by one.
 To route the output to a different input than the one currently connected to,
hit the “candidate” input channel number. This does not actually make the
connection; the new input channel will be blinking. Again if you change your
mind, either hit the same blinking button (it will stop blinking), or hit another
input channel. When you are sure you have selected the input channel you
desire, hit SET.
 The output can’t be disconnected from the input. It is always being routed
from one of the inputs.
 Note that once you enter the channel routing mode from the front panel, if
you do not hit any buttons for approximately 8 seconds, the system will exit
this mode without any user interaction.
Standing By …
Press PWR to turn on
To View/Route AV
Use VID/AUD Btns
