Glow-worm 56/3 Back Boiler - Manual (Page 3)

3 221724B
C
L of Flue
C
L
FLUE
1 General
OVERALL DIMENSIONS
6837
Diagram 1.1
E
A
B
C
D
F
G
H
J
K
L
WATER
CONNECTIONS
22mm COPPER PIPE
GAS CONNECTION
RC (
1
/
2
in BSPT)
SIDE ELEVATION FRONT ELEVATION
J M
N
FIRE FIXING WALL FACE
P
R
S
T
INSIDE DIAMETER
OF SOCKET FOR
125mm (5in)
NOMINAL DIAMETER
FLUE
Dimension A B C D E F G H J K L M N P R S T
56/3pp 550 400 338 337 245 130 3 146 177 174 60 457 65 530 80 50 490
INJECTOR
MARKING
RANGE RATING
HEAT kW
INPUT
(NETT)
Btu/h
HEAT kW
OUTPUT
Btu/h
HOT mbar
BURNER
PRESSURE
in.w.g
10.8 14.5 17.6 18.2
36,950 49,550 59,900 62,150
RANGE RATING TABLE
3.6 Pt. No. 230208
Minimum Medium Maximum Maximum
Brown Ember 3 Miami 3
Black Ash 3 Melody 3
Saxony 3
9.4 12.9 15.8 16.4
32,000 44,000 54,000 56,000
5.1 9.2 13.7 14.8
2.0 3.7 5.5 5.9
