INSTALLATION
• Using the buttons
,
select
external T ºC correction on
the screen.
• Press the button
to confirm.
This setting is automatically modified in
the installer room thermostat menu.
• Increase or decrease with the
buttons
to display the
desired correction.
• Press the button
to confirm.
• Press the button
twice.
12.6 Self check
e
Do not modify the cables when connected to the
mains.
The automatic test allows you to check:
- EBUS inputs,
- NTC inputs,
- the RF connection with the room thermostat,
- the outdoor sensor radio connection.
The other connections are not tested and should be
visually inspected during installation or configuration
modifications.
• Using the buttons
,
select
Self check on the screen.
• Press the button
to confirm.
• Check that all installation’s
components are switched on.
• Confirm the start of the test with the
button
.
The automatic test will start.
The results appear in seconds,
indicating the status of each
component.
- If the connection is correct, the
message "OK" appears opposite the
component.
- If the connection is not correct, the
message "Not OK" appears opposite
the component.
In this case, check the connections.
12.7 Settings
This menu allows you to adjust different functions in accordance
with the connected appliances and to reset all the parameters.
• Using the buttons
,
select
Settings on the screen.
• Press the buttony
to confirm.
