1 introducing the fva-600 variable attenuator, Main features – EXFO FVA-600 User Manual
Page 7
FVA-600
1
1 Introducing the FVA-600
Variable Attenuator
The FVA-600 is a variable optical attenuator used for bit error rate and system
testing, optical margin analysis, calibration verification and component testing. It is
configured for singlemode fibers. Calibrated wavelengths are 1310 nm and 1550 nm.
Main Features
The FVA-600 includes the following:
³
Large attenuation range
³
High accuracy
³
Fast settling time
³
Auto-off feature to lenghten battery life
³
Backlight to help you work regardless of external conditions
³
Unit status and operation mode stored upon shutdown
³
Remote operation using a USB link
LCD display
Keypad
Shoulder
strap eyelet
DC connector
Safety label
and serial number
(under the stand)
Quick reference label
Battery compartment
USB connector
