SONET/SDH Application 429
18 Next-Generation Tabs
The Next-Generation tabs include GFP, VCAT and LCAS tabs allowing
configuration and to view the test status and results.
Note: The available tabs listed are a function of the test path activated. GFP,
VCAT, and LCAS are available with ODU2, ODU1, and optical SONET/SDH
interfaces on FTB-8120NG, FTB-8120NGE, FTB-8130NG, and FTB-8130NGE
only. Refer to OTN/SONET/DSn Interface Path/Mapping on page 60 and
OTN/SDH/PDH Interface Path/Mapping on page 61 for more information.
Next-Generation tabs are not available with Decoupled test mode.
Tab Page
GFP
(GFP-F)
or GFP-T
GFP Overview TX 431
GFP Frame TX 435
GFP Channel TX 435
GFP Channel Stats TX 439
GFP OH TX 440
GFP Client TX 444
GFP Overview RX 447
GFP Frames RX 449
GFP Channel RX 451
GFP Channel Stats RX 454
GFP OH RX 455
GFP Client RX 457
