Page 34
Physical Interfaces and LEDs
20
FTB-8100 Series Transport Blazer
OTN/OC-N/STM-N Interface Connections
Carefully connect optical fibre cables to the SFP/XFP’s (FTB-8115,
FTB-8120, FTB-8120NG, FTB-8120NGE, FTB-8130, FTB-8130NG, and
FTB-8130NGE) or transponder (FTB-8140) IN and OUT ports. To ensure
good signal quality, make sure that the optical fibre connector is fully
inserted into the optical connector port.
³
LASER red LED: The LASER LED is on when the FTB-8100 Series is
emitting an optical laser signal.
³
RX green LED: The RX LED is on when the FTB-8100 Series is receiving
an optical laser signal.
C
AUTION
To prevent exceeding the maximum input power level please use an
attenuator when a loopback configuration is used.
