Analyzing Traces with the Bidirectional Analysis Application (Optional)
258 FTB-700 Series
Exporting Unidirectional Traces from Bidirectional Files
To export unidirectional traces from a bidirectional file:
1. Create a bidirectional measurement (see Creating Bidirectional
Measurement Files on page 195).
OR
Open an already existing file (see Opening Existing Bidirectional
Measurement Files on page 199).
2. From the Main Menu, select Export.
3. Select either Export A->B or Export B->A.
4. From the Save As dialog box, select a folder or create one to save your
file.
5. If desired, modify the file name.
6. Press Save to confirm.
The exported trace is now available.
I
MPORTANT
If you specify the name of an existing trace file, the original file will
be overwritten and only the new file will be available.
