Analyzing Traces with the Bidirectional Analysis Application (Optional)
240 FTB-700 Series
Setting General Parameters
To set the general parameters:
1. From the Main Menu, select Setup, then select the General tab.
2. Select the boxes corresponding to the item you want to display on the
graph.
OR
To hide them, clear the boxes.
3. Press Apply to confirm the changes, then OK to return to the main
window.
The changes are applied automatically.
To revert to factory default settings:
1. From the Main Menu, select Setup, then select the General tab.
2. Press the Revert to Factory Settings button.
Note: Only the parameters from the current tab have been reset.
To display a black
background
