Analyzing Traces with the Bidirectional Analysis Application (Optional)
OTDR
209
Viewing Results
To quickly locate an event in the events table:
1. Ensure that the
button is selected in the zoom button bar.
2. Select the event on the trace.
The list scrolls automatically to the event you selected.
Graph
Event no. 4
Events table
Zoom-on-
event button
