Mportant – EXFO FTB-5230S Optical Spectrum Analyzer for FTB 200 v2 User Manual
Page 70
Setting Up the Instrument in WDM Mode
64
FTB-5230S/-OCA
Setting Up WDM Analysis Parameters
Defining General Settings
The general analysis parameters for WDM acquisitions affect the
calculation of the results. Any change you make to the settings affect future
traces, or you can apply them to the active trace when reanalyzing it.
To define general settings:
1. From the Main Menu, press Analysis Setup.
I
MPORTANT
In the General tab, you can set the default channel parameters. Any
channel found during an acquisition that is not defined in the
channel list will be analyzed according to the default channel
settings.
