Results tab – EXFO FTB-5230S Optical Spectrum Analyzer for FTB 200 v2 User Manual
Page 187
Managing Results
OSA/OCA
181
Managing WDM Test Results
Results Tab
In the Results tab, each channel will be represented for both the active and
reference traces, with the delta between both results. Only the results for
the channels within the scan range will be analyzed. The pass (
)/fail
(
) verdict for thresholds are also displayed; if the verdict is fail for any
parameter, its value will appear in red.
To view results:
From the main window, select the Results tab.
Note: For details on filtering displayed channel results, see Defining Display
For details on each result type, see Customizing WDM Results Table on
page 59.
