Pc card slot, Inserting and removing pc cards, Pc card slot -7 – Eurocom M560A DIVINE User Manual
Page 49: Inserting and removing pc cards -7
Features & Components
PC Card Slot 2 - 7
2
PC Card Slot
The computer is equipped with a PCMCIA 3.3V/5V slot for one type II PC-
MCIA CardBus PC Card Slot. Make sure you install the PCMCIA/Card Read-
er Card driver (see
“PCMCIA/Card Reader” on page 4 - 10
).
Inserting and Removing PC Cards
• Align the PC Card with the slot and push it in until it locks into place.
• To remove a PC Card, simply press the eject button
next to the slot.
Figure 2 - 5
PC Card Slot
PC Card Slot Cover
Make sure you keep
the cover in the PC
Card slot when not is
use. This will help pre-
vent foreign objects
and/or dust getting in
to the PC Card Slot.
1
Model B (Right)
Model A (Right)
1
1
