30 - Specifications
Concise User’s Guide
English
Communication
Built-In Giga Base-TX Ethernet LAN
(Factory Option) 3.0M Pixel USB PC Cam-
era Module
(Factory Option) Bluetooth 2.1 + EDR
(Enhanced Data Rate) Module
Wireless LAN Module Options:
(Factory Option) Intel® WiFi Link 6200
(802.11a/g/n)
Wireless LAN Half Mini-Card
Module
(Factory Option) Intel® WiFi Link 6300
(802.11a/g/n)
Wireless LAN Half Mini-Card
Module
(Factory Option) Third-Party 802.11b/g/n
Wireless LAN Half Mini-Card Module
Card Reader
Embedded 8-in-1 Card Reader (MS/ MS
Pro/ SD/ Mini SD/ MMC/ RS MMC/ MS Duo)
Note: MS Duo/ Mini SD/ RS MMC Cards
require a PC adapter
Mini Card Slots
Slot 1 for WLAN Module
(Factory Option) Slot 2 for TV Tuner Mo d-
ule or Turbo Memory Module
Interface
Three USB 2.0 Ports
Two USB 3.0 Ports
One eSATA Port
One HDMI-Out Port
One HDMI-In Port
One DVI-Out Port
One S/PDIF Out Jack
One Headphone/Speaker-Out Jack
One Microphone-In Jack
One Line-In Jack
One Mini-IEEE1394b Port
One RJ-45 LAN Jack
One DC-In Jack
One Consumer Infrared Port for Optional
TV Tuner Remote Control
One CATV Antenna Jack (for Optional TV
Tuner)
Audio
High Definition Audio Compliant Interface
S/PDIF Digital Output
Four Speakers
One Sub Woofer
Built-In Microphone
Dolby Home Theater (5.1 Channel) Certified
Environmental Spec
Temperature
Operating: 5 ° C - 35 ° C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Full Range AC/DC Adapter – AC in
100 - 240V, 50 - 60Hz DC Output 20V,15A
(300 Watts)
Removable Polymer Smart Lithium-Ion Bat-
tery Pack, 88.8WH
Dimensions & Weight
419mm (w) * 286mm (d) * 60.7mm (h)
Around 5.5 kg with Battery and ODD
