System Map: Front, Left & Right Views - 11
Concise User’s Guide
Engl
ish
System Map: Front, Left & Right Views Figure 6
Front, Left & Right Views
1. Speakers
2. Consumer Infrared
Transceiver
3. LED Power Indicators
4. DVI-Out Port
5. Cable (CATV) Antenna
Jack
*
6. RJ-45 LAN Jack
7. HDMI-Out Port
8. USB 3.0 Ports
9. eSATA Port
10. Mini-IEEE 1394 Port
11. HDMI-In Port
12. 8-in-1 Card Reader
13. Optical Device Drive Bay
14. Line-In Jack
15. S/PDIF-Out Jack
16. Microphone-In Jack
17. Headphone-In Jack
18. USB 2.0 Ports
19. Security Lock Slot
5
8
6
7
2
3
1 1
4
Front
10
Left
Right
11
19
18 17 16
12
15
13

USB 3.0 Port
The USB 3.0 port is denoted by its blue color; USB 2.0 ports are colored black. USB 3.0 will
transfer data much faster than USB 2.0, and is backwards-compatible with USB 2.0.
9
1
8
14 18 18
