1 - 18 System Map: Left View
Quick Start Guide
1
System Map: Left View
Figure 1 - 9
Left View
1. Security Lock Slot
2. RJ-45 LAN Jack
3. Multi-In-1 Card
Reader
4. Line-In Jack
5. S/PDIF-Out Jack
6. Microphone-In
Jack
7. Headphone-Out
Jack
See
detailed description of the
ports & jacks etc.
1
3
4
5
6
7
2
Multi-in-1 Card Reader
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / RSMMC
SD (Secure Digital) / Mini SD / SDHC / SDXC
MS (Memory Stick) / MS Pro / MS Duo
