Eurocom P370EM Scorpius User Manual
Page 257
Interface (Ports & Jacks)
Interface (Ports & Jacks) A - 5
A
USB 2.0/1.1 Ports*
USB 3.0 Port
Powered USB 3.0 Port
USB (Universal Serial Bus) 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for
low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such
as external HDDs, digital video cameras or high-speed scanners etc. Devices can be plugged
into the computer, and unplugged from the computer, without the need to turn the system off (if
the power rating of your USB device is 500mA or above, make sure you use the power supply
which comes with the device).
USB 3.0 ports on the computer are denoted by their
blue color
. USB 3.0 will transfer data much
faster than USB 2.0, and is backwards-compatible with USB 2.0. The USB 3.0 ports require a
driver installation (see
Note: The powered USB 3.0 port (see
“System Map: Right View” on page 1 - 16
) may be tog-
gled on /off by means of the Fn + Power Button key combination (press for around 1 to 2 sec-
onds to toggle). When the powered USB port is on it will supply power (for charging devices
only, not for operating devices) when the system is off but still powered by the AC/DC adapter
plugged into a working outlet, or powered by the battery with a capacity level above 20% (this may
not work with certain devices - see page
Note: This function is designed to help charge USB compliant devices, but is not designed to
allow their operation.
Item
Description
3.
0
3.
0
