1 - 10 Keyboard Backlight LED
Quick Start Guide
1
Keyboard Backlight Application
The keyboard Backlight application can be accessed by pressing the Fn plus key. Click the Help button
in the application to display the configuration keys.
• Click the Custom button to display the three sections of the keyboard which may be configured.
• Click a section of the keyboard and the color buttons will be displayed.
• Click a color swatch to apply the color to the selected section when not overridden by any effect applied.
• Click on any of the effect buttons to apply random colors, wave or flashing effects etc (see over).
Figure 1 - 4 - Keyboard Backlight Application
Help Button
Keyboard Sections
Color Swatches
Effects Buttons
