1 - 10 LCD Panel Open - Model F
Quick Start Guide
1
LCD Panel Open - Model F
Figure 1 - 5
LCD Panel Open
Model F
1. Built-In PC Camera
2. PC Camera LED
3. Built-In Microphone
4. LCD
5. Speakers
6. LED Indicators
7. Power Button
8. Illuminated Keyboard
9. TouchPad and
Buttons
10. Fingerprint Reader
(Optional)
4
1
9
10
5
8
7
6
5
2 3
Note that the Illumi-
nated Touchpad has a
defined valid opera-
tional area of sensitiv-
ity indicated within the
sensor area of the il-
lustration below. See
