Upgrading The Computer
6 - 28 Upgrading the System Memory (RAM)
6
Removing the Component Cover (Model F)
1. Turn the computer off, remove the AC/DC adapter (and battery) and turn the computer over.
2. Remove screws - from the bottom and rear of the computer
.
3. Slide the component bay cover until the cover and case indicators are aligned.
4. Lift the cover off the computer.
Figure 6 - 27
Component Cover
Screws
(Model F)
Figure 6 - 28
Component Cover
Move & Removal
(Model F)
1 6
1
2
3
4
5 6
7
8
8
7
