Concise User’s Guide
3.5G Module - 29
Engl
ish
3.5G Module
If you have included an optional 3.5G module in your
purchase option, follow the instructions below to install
the USIM card (which will be provided by your service
provider), and then install the application.
1.
Turn off the computer, and turn it over and remove the
battery.
2.
Locate the hard disk bay cover and remove screws
&
.
3.
Remove the hard disk bay cover
.
4.
Grip the tab and slide the hard disk in the direction of
arrow
to remove it.
Figure 13 - Hard Disk Removal
5.
Insert the USIM card as you would into your mobile phone.
6.
The 3.5G module
is pictured on the left, and the
installed USIM card
Figure 14 - Module & USIM Card Location
Power Safety Warning
Before you undertake any installation procedures, make sure
that you have turned off the power, and disconnected all pe-
ripherals and cables (including telephone lines). It is advisable
to also remove your battery in order to prevent accidentally
turning the machine on.
1
2
3
4
3
2
1
4
5
6
5
6
