10 - System Map: Front View with LCD Panel Open (Model B)
Concise User’s Guide
English
System Map: Front View with LCD Panel Open
(Model B)
Figure 3
Front View with LCD
Panel Open (Model B)
1.
Built-In PC Camera
(Optional)
2.
LCD
3.
Power Button
4.
Hot-Key Buttons
5.
LED Status Indicators
6.
Keyboard
7.
Touchpad & Buttons
8.
LED Power &
Communication
Indicators
9.
Fingerprint Module
(Optional)
10. Built-In Microphone
Note the cleaning in-
structions for alumi-
num covers - see
2
1
7
8
4
5
9
3
6
10
Wireless Device
Operation Aboard Aircraft
The use of any portable electronic transmission
devices aboard aircraft is usually prohibited.
Make sure the wireless modules are OFF if
you are using the computer aboard aircraft.
Use the appropriate function key combination
(see
) to toggle power to
the wireless modules (3.5G/WLAN/Bluetooth),
and check the LED indicator
/
to see if
the modules are powered on or not (see
Table 2, on page 11
).
TouchPad buttons
(valid operation area)
7
