System Map: Front View with LCD Panel Open (Model A) - 9
Concise User’s Guide
Engl
ish
System Map: Front View with LCD Panel Open
(Model A) Figure 2
Front View with LCD
Panel Open (Model A)
1. Built-In PC Camera
(Optional)
2. LCD
3. Speakers
4. Power Button
5. Hot-Key Buttons
6. LED Status Indicators
7. Keyboard
8. Touchpad & Buttons
9. LED Power &
Communication
Indicators
10. Fingerprint Module
(Optional)
11. Built-In Microphone
Note the cleaning in-
structions for alumi-
num covers - see
page 7 .
2
5
1
7
8
4
6
9
3 3
11
10
Wireless Device
Operation Aboard Aircraft
The use of any portable electronic
transmission devices aboard aircraft is
usually prohibited. Make sure the
wireless modules are OFF if you are
using the computer aboard aircraft.
Use the appropriate function key com-
bination (see
Table 4, on page 13 ) to
toggle power to the wireless modules
(3.5G/WLAN/Bluetooth), and check
the LED indicator
/ to see if
the modules are powered on or not
(see
Table 2, on page 11 ).
