System Map: Left View - 15
Concise User’s Guide
Engl
ish
System Map: Left View Figure 6
Left View
1. DC-In Jack
2. RJ-45 LAN Jack
3. External Monitor Port
4. Vent
5. 2 * USB 2.0 Ports
6. ExpressCard/54(34)
Slot
1
4
2
5
6
3
5 Model A
Model B
ExpressCard Slot
The ExpressCard slot accepts either Express-
Card/34 or ExpressCard/54 formats.
1
4
2
5
6
3
5
Overheating
To prevent your computer from over-
heating make sure nothing blocks the
vent while the computer is in use.
