Modules & Options
7 - 34 Intel Turbo Memory Module
7
Intel Turbo Memory Module
If you have included an Intel Turbo Memory (Robson) NAND flash memory card
module
in your purchase option, then you will need to install the driver as per the
instructions below (do not install this driver in Windows XP).
Intel Turbo Memory Technology (also known as Robson flash memory) is an Intel
technology that reduces the time it takes for a computer to boot up, to load applica-
tions, and to write data to the hard drive. Intel Turbo Memory Technology is sup-
ported in Windows Vista only (it also supports Windows Vista features such as
ReadyBoost, ReadyDrive, and Superfetch).
Intel Turbo Memory Driver Installation
1.
Start-up the computer and press <F2> to enter the BIOS (see “The Setup
Utility” on page 5 - 4 ).
2. Go to the Advanced menu, select "Installed O/S" and make sure "Vista" is
the selected option (see “Advanced Menu” on page 5 - 8 ).
3. Go to the "SATA Mode Selection" item and make sure "AHCI" is selected.
4. If "AHCI" is the selected mode then the "DFOROM (Robson) Support"
item will be available.
5. Set the "DFOROM (Robson) Support" item to "Enabled".
6. Go to the Exit menu (see
“Exit Menu” on page 5 - 14 ) and select "Exit
Saving Changes" (or press F10 and select "Yes" then press Enter) and
press Enter to exit the BIOS and reboot the computer.
