System map: front & left views – Eurocom Armadillo User Manual
Page 42
1 - 12 System Map: Front & Left Views
Quick Start Guide
1
System Map: Front & Left Views
Figure 1 - 5
Front & Left Views
1.
LED Power
Indicators
2.
Security Lock Slot
3.
Microphone-In
Jack
4.
Headphone-Out
Jack
5.
Vent/Fan Intake/
Outlet
6.
Speaker
2
3
1
5
4
Overheating
To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake
while the computer is in use.
6
